RUBBER SHEET

Liquid phase rubber sheet

< >

Product Introduction

RIO liquid phase rubber is a natural rubber with a content of more than 95%, providing excellent resistance to wet abrasion, tearing and cutting. The unique latex liquid phase process delivers exceptional physical properties and outstanding performance at significantly reduced cost to the customer, making RIO Liquid Phase Rubber a premium abrasion-resistant rubber for wet grinding conditions, especially for slurry conveying.

RIO Liquid Phase Rubber is a renewable resource and environmentally friendly, using natural latex to minimize the impact on the environment and resources, while maximizing safety, reliability and operational efficiency.


Features

    Proven top slurry wear resistance

    Good combination of mechanical properties

    high coefficient of friction

    High resilience and low modulus

    Excellent chemical resistance

    Excellent cut and tear resistance

    Environmental properties of natural latex

Physical properties

Testing ProgramTesting StandardsRui Ao Liquid Phase Rubber
Tensile strength (MPa)lSO 37: 2011>26
Elongation (%)lSO 37: 2011>820
Tear strength (N/mm)ASTM D624 00-2012>45
Hardness (SHa)ISO 48-201035±3
Specific gravity (g/cm3)lsO 2781-20080.95-0.98
Rebound rate(%)BS 903-Part A8:1990>80
Wet grinding index
1.0-1.2
Operating temperature
-40'C~70'c


Standard Plate Size

Length 9250 mm × Width 1230 mm

Thickness

1.5 mm ~ 35.0 mm

Application Scenario

Slurry pipe lining

Slurry hoses

slurry pumps

Slurry valve lining

Hydrocyclone liners

Slurry tank liners

Screens

Filter press rubber membrane

Applicable methods

Hot vulcanization bonding

Cold bonding

High temperature molding
